5.1.2 Quiet Time
Quiet Time is a time period during which the MATE2M will not allow most AGS settings to start the generator. This is usually
set-up as night time when a running generator would be an annoyance. Quiet Times can be set individually for weekday and
weekend, and consist of a Quiet Time Start and a Quiet Time Stop.
MATE2M System Controller and Display User Manual Copyright 2003
© OutBack Power Systems, Inc.
19009 62 nd Ave NE, Arlington WA 98223 USA
Page 18 Rev 1.00 03/31/04 Tel 360 435 6030 Fax 360 435 6019
WEEKDAY START:
Weekday Quiet Time start is the beginning of the quiet time period for Mon -
Fri, most AGS start conditions will be stopped at this time. Press
to adjust the hour and minutes settings.
ADV/MATE/AGS/QT----------
weekday: 12:00A
quiet time start
DOWN AGS CHANGE
WEEKDAY STOP:
Weekday Quiet Time stop is the end of the quiet time period for Mon - Fri.
Press to adjust the hour and minutes settings.
ADV/MATE/AGS/QT----------
weekday: 12:00A
quiet time stop
DOWN UP CHANGE
WEEKEND START:
Weekend Quiet Time start is the beginning of the quiet time period for Sat &
Sun, most AGS start conditions will be stopped at this time. Press
to adjust the hour and minutes settings.
ADV/MATE/AGS/QT----------
weekend: 12:00A
quiet time start
DOWN UP CHANGE
WEEKEND STOP:
ADV/MATE/AGS/QT----------
weekend: 12:00A
quiet time stop
DOWN UP CHANGE
Weekend Quiet Time stop is the end of the quiet time period for Sat & Sun.
Press to adjust the hour and minutes settings.
5.1.3 Voltage Start
There are three voltage start setpoints in AGS Mode that the user can adjust. After a generator is started due to a Voltage
Start setting, it will be stopped when the FX reaches Float or Silent mode, or based on the VDC Genstop setting in AGS
Setup menu previously explained.
24 Hour voltage setpoint:
ADV/MATE/AGS/VSTART--
Volt start 24.4 vdc
24 hr setting
DOWN AGS INC DEC
If the battery voltage falls below this setpoint, a 24 hour timer starts to count
down. On reaching zero, a genstart is sent to the FX inverter unless it is
currently Quiet Time.
2 Hour voltage setpoint:
If the battery voltage falls below this setpoint, a 2 hour timer starts to count
down. On reaching zero, a genstart is sent to the FX inverter unless it is
currently Quite Time.
ADV/MATE/AGS/VSTART--
Volt start 23.6 vdc
2 hr setting
DOWN UP INC DEC
ADV/MATE/AGS/VSTART--
Volt start 22.0 vdc
2 min setting
DOWN UP INC DEC
2 Minute voltage setpoint:
If the battery voltage falls below this setpoint, a 2 minute timer starts to count
down. On reaching zero, a genstart is sent to the FX inverter even if it is
currently Quite Time.
