Removing the mounting bracket – DAVIS Vantage Pro ISS Retrofit Kit for Fan-Aspirated Station User Manual
Page 15
Installation Outline
Page 15
6.
Remove the top two (2) radiation shield plates to expose the fan plate and
junction board.
2" Screws (3)
Lock Washers
Flat Washers
Closed Plate
(no hole in center)
Open Plate
(hole in center)
Solar Power
Cable
SOLAR MODELS
Power Cable
AC MODELS
Sensor
Cable
Fan Plate
Battery Compartment
Mounting Bracket
SOLAR MODELS
Mounting
Bracket
AC MODELS
Junction Board
Direction
of air flow
Removing the Mounting Bracket
ISS2 SPARS RetroKit D011.fm Page 15 Wednesday, April 23, 2003 11:26 AM
