JKS2030 - JKS2034
JKS Quicker Disconect Installation
Page 5
5. INSTALL QUICKER DISCONNECTS
Slide Upper Ends (G) and Lower Ends (I) of
Quicker Disconnects onto the Tapered Mounting
Posts (C, K & M).
Insert Click Pins (J) as illustrated to secure.
When properly installed, the ring on the Click Pin will
“snap” against the shaft of pin. When installed back-
wards, the ring does not fit snugly against shaft.
CAUTION
When properly installed, the ring on the Click Pin will
“snap” against the shaft of pin. When installed backwards,
the ring does not fit snugly against shaft.
6. LUBRICATE QUICKER DISCONNECTS
Lubricate all Grease Zerk fittings on the Quicker
Disconnects immediately after installation using
common wheel bearing grease or equivalent.
