2-57
2.7 LED STATUS INDICATOR
A Light Emitting Diode (LED) is incorporated into the body of
the AN/PEQ-2A (adjacent to the Safety Block) that provides
indicators as shown in Table 2-9. Batteries should be
replaced promptly upon receiving a low battery power
indication.
Table 2-9 LED Status Indicator
Indicator
Color
Indicator
Rate
AN/PEQ-2A Status
GREEN Solid Laser(s) activated
GREEN
1 Flash per
Second
Laser(s) activated, low battery
power
Figure 2-37 LED Status Indicator
LED
Status Indicator
