2.3.9 M60 Machine Gun Using M60 Mounting Bracket. The
AN/PEQ-2A may be mounted on the M60 Machine Gun
using the M60 Mounting Bracket and Bracket Adapter.
WARNING ..
Be sure the weapon is CLEAR and SAFE before
proceeding.
NOTE
Failure to fully tighten the Mounting Bracket,
Bracket Adapter or AN/PEQ-2A thumbscrew may
cause zero retention problems.
a. Remove the M60 hinge pin latch and hinge pin from
the cover assembly. Place the pin latch in the
aiming guides on the left side of the Mounting
Bracket and press together.
b. Place the Mounting Bracket on top of the feed tray
cover so that the holes in the front of the bracket
align with the cover assembly pin holes.
c. Insert the longer hinge pin (supplied with the
bracket) through the bracket and cover assembly,
and secure by inserting the hinge pin latch.
d. Turning counterclockwise, loosen the wing nuts on
both leg clamps and position the leg clamps under
the cover assembly. Secure the Mounting Bracket
by tightening the wing nuts firmly. The split washer
should be next to the wing nut and the flat washer
next to the bracket.
e. Place the Bracket Adapter in the AN/PEQ-2A
mounting groove, flush with the front of the AN/PEQ-
2A. Turn the thumbscrew clockwise to tighten. Use
