2-43
Figure 2-28 Illuminator Adjusters (Right Side Mounted)
Table 2-6 Beam Movement for the IR Illuminator
(Right Side Mounted)
Adjuster Rotation
Beam
Movement
Top Adjuster
Elevation CW
CCW
Down
Up
Side Adjuster
Windage CW
CCW
Left
Right
TOP ADJUSTER
SIDE ADJUSTER
