2-2
2.2 BATTERY HANDLING
2.2.1 Battery Inspection. Before installation, inspect the
batteries for any cracks, dents, leakage, or bulging. Never
install a defective battery in the AN/PEQ-2A.
WARNING
..
Ensure the Mode Selector is turned to the OFF (0)
position before attempting to install, remove or
replace batteries.
2.2.2 Battery Installation. Unscrew the Battery Caps and
install one AA battery in each compartment as shown in
Figure 2-1. Proper battery orientation is clearly marked on
the AN/PEQ-2A housing. Replace and tighten the Battery
Caps.
Figure 2-1 Battery Installation
Battery Orientation
Markings
