2-49
SECTION II
OPERATING PROCEDURES
2.5 MODES OF OPERATION
Table 2-8 describes the modes of operation for the AN/PEQ-
2A.
Table 2-8 Mode Selector Positions
Position Mode Remarks
0 OFF
The AN/PEQ-2A will not operate.
Prevents inadvertent emission of
laser energy.
1
AIM LO
Class 1
IR Aim Laser is selected at low
power.
2
DUAL LO
Class 3R IR Aim Laser and IR Illuminator
are both selected at low power.
3
AIM HI
Class 3B
IR Aim Laser is selected at high
power.
4
DUAL LO/HI
Class 3B
IR Aim Laser is selected at low
power and IR Illuminator is
selected at high power.
5
DUAL HI/HI
Class 3B
IR Aim Laser and IR Illuminator
are both selected at high power.
WARNING ..
The Class 1 and 3R lasers (low power) described
in Table 2-8 may be used in force-on-force training
only if opposing forces are beyond the NOHD
values shown in Table a-1.
