2-4
Weapon
Configuration
Bracket / Adapter Paragraph
M240B
Picatinny Rail Grabber on Feed Tray
Cover Rail
2.3.11
M240B
Insight Low Profile Rail Grabber on Left
or Right Forward Rails
2.3.12
M240B
Picatinny Rail Grabber on Left or Right
Forward Rails
2.3.13
M2 AN/TVS-5 Bracket and Adapter 2.3.14
Mk 19 AN/TVS-5 Bracket and Adapter 2.3.15
M4/M16 w/
MILES
M4/M16A2 Bracket Assembly OR
Insight Low Profile Rail Grabber AND
Training Extender Bracket
2.3.16
2.3.1 M16A2 Using M4/M16A2 Bracket Assembly. The
AN/PEQ-2A mounts to the M16A2 using an M4/M16A2
Bracket Assembly.
WARNING ..
Be sure the weapon is CLEAR and SAFE before
proceeding.
a. Use a 3mm hex head wrench to completely
disassemble the M4/M16A2 Bracket Assembly as
shown in Figure 2-2.
