Safety & Specifications
5201
Frequency 10MHz to 18.5GHz
Measurement range -50 to +20dBm CW
Operating Temperature 0 to 50 deg C
Shock 25G, 11 ms
Vibration 15G, 100 to 2000Hz
Linearity error +/-0.27 dB; -40dBm to +10dBm;
greater than or equal to 50 MHz
+/-0.49 dB; +10dBm to +20dBm;
greater than or equal to 50 MHz
+/-0.28 dB; -40dBm to +10dBm; less than 50 MHz
+/-0.95 dB; +10dBm to +20dBm; less than 50MHz
Cal factor error 25 +/- 5 deg C +/-0.24 dB; 10 MHz to 50MHz
+/-0.19 dB; 50MHz to 4.5GHz
+/-0.23 dB; 4.5GHz to 8.5GHz
+/-0.32 dB; 8.5GHz to 12.4GHz
+/-0.38 dB; 12.4GHz to18.5GHz
Linearity variation 25 +/- 25 deg C +/-0.35 dB; 50MHz to18.5GHz
+/-0.47 dB; 10 MHz to 50MHz
Cal factor variation 25 +/- 25 deg C +/-0.32 dB; greater than or equal to 50 MHz
+/-0.44 dB; less than 50 MHz
Zero set +/-1.8 nW
Noise 0.15 nW RMS
Input SWR - max 1.26:1 = 18.5 GHz
Measurement Speed: -50 to -5 dBm 8 measurements per sec.
-5 to -20 dBm 33 measurements per sec.
-20 to +20 dBm 50 measurements per sec
Max input power (damage level) 200mW CW (+23dBm)
Connector type SMA (m)
Connectivity USB 2.0 (cable length up to 5m)
USB power supply current Approx. 50mA
Sensor Cable Length (std) 76” (193 cm)
Dimensions (max) H x W x L 1.34” x 1.69” x 4.92” (34 x 43 x 125 (mm)
Weight 0.18lb (83 grams)
Specifications include expanded uncertainty of measurement stated as the standard uncertainty of
measurement multiplied by the coverage factor k=2 which corresponds to a coverage probability of
approximately 95% for abnormal distribution.
