2 Using the Software
5. Choose Use Table in the calibration factor section of the control
dialog box. This uses the sensor’s internal calibration table.
Refer to Figure 22 on page 28.
Figure 22 Use table
6. Select Apply and Close the measurement control panel.
Figure 2 Apply button
7. Enable the unit under test (UUT) providing a signal to the sensor.
8. The power measurement is displayed.
For definitions of dB and dBm, refer to “What is a dB?” on page 57
and “What is a dBm?” on page 58.
Measurements using more than one sensor
It is possible to make multiple measurements using multiple USB
sensors and multiple instances of the sensor software. Start the Boonton
software for each sensor connected to your PC. Follow this procedure:
