AirSep ® Corporation
NewLife ® Elite Service Manual
5.0 Service
5.1 Components
The design of the AirSep NewLife Oxygen Concentrator allows for easy access
and removal of most components. This allows you to perform scheduled
maintenance, repair, and replacement of parts with minimal time and effort.
CAUTION
For your safety, be sure to set the ON/OFF switch to
the OFF position and unplug the power cord of the unit
before you service the NewLife Oxygen Concentrator.
NOTE
Record all scheduled maintenance. (Refer to Section 4.0.)
5.2 Cabinet Removal
5.2.1 Removing Side Panel(s)
To remove one or both side panels, unscrew the 1/4 turn fas tener(s)
and remove the panel(s).
5.2.2 Removing Back Panel
Remove both side panels, and lift off the back panel. Make sure the
power cord can pass freely through the power cord cutout.
5.2.3 Removing Lower Front Cover
Firmly grasp panel with both hands, and slightly bow panel outward
to remove.
5.2.4 Removing Control Panel
Four screws hold the control panel in place. Remove them and the
control panel to re-install or replace if necessary.
5.2.5 Superstructure
The weight and forces of the internal components rest solely on three
parts: the superstructure, compressor plate, and the base. These parts
were specially designed and formed. They should never require
replacement under normal use.
5-1
