Focus™
EN
AirSep
®
Corporation EN-37
MN172-1 rev. A - 02/13
Focus Specifications
Oxygen
Concentration:* Pulse setting equivalent to a continuous flow of 90%
oxygen
Ŕ 3% / +5.5%
Pulse Dose: 17.25ml ± 10%
Dimensions: 6.4 in. high x 4.8 in. wide x 2.5 in. deep (16.4 cm high x
12.2 cm wide x 6.1 deep)
Weight: Concentrator 1.75 lb (0.8 kg)
Battery 0.53 lb (0.2 kg)
Optional AirBelt Battery 1.8 lb (0.8 kg)
Power: Universal Power Supply:
AC Power Supply: Input # 1_100
Ŕ 240 VAC (1.5 Amps
max at 120 VAC 50/60 Hz)
DC Power Supply: Input # 2_11-16 VDC 5.0 Amps max
Battery duration
(Rechargeable lithium
Battery) Battery:
1 ½ hours (per battery)
Optional AirBelt Battery: 4 hours
Battery recharge time: 4 hours; optional AirBelt: 3 hours
Warm-up time: 2 minutes
Battery cycle life: Approximately 300 cycles, then 80% capacity or below.
Audible alarms and
pulse visual indicators: Start-up
Ŕ audible and visual
Pulse flow Ŕ visual
Cannula disconnect Ŕ audible and visual
Breath rate alarm Ŕ audible and visual
General malfunction
Ŕ audible and visual
Service required
Ŕ visual
Low battery
Ŕ audible and visual
Battery condition
Ŕ battery level indicator
on battery
**Temperature range: Normal operating temperature:
41°F to 104°F (5°C to 40°C)
Up to 95% RH (non-condensing)
Storage temperature:
-
4°F to 140°F (-20°C to 60°C)
**Operational Altitude: Operational Altitude: up to 10,000 ft. (3,048m)
(523 mmHg) Higher altitudes may affect performance
* Based on an atmospheric pressure of 14.7 psi (101 kPa) at 70°F (21°C)
**Operating outside of these operational specifications can limit the concentrator's ability to meet
Oxygen Concentration specification at higher liter flow rates.
