Focus™
EN-16 AirSep
®
Corporation
MN172-1 rev. A - 02/13
Figure: 9
Bag with Battery Pockets: The Focus with carrying bag (Item 1) can be placed
in the bag with battery pockets (Item 10). This will allow you the ability to carry
additional battery power in one bag while still operating the Focus.
The Focus shoulder strap(Item 9) can be used with either the Focus in the
carrying bag (Item 1) or with the Focus with carrying bag (Item 1) placed in the
Focus bag with battery pockets (Item 10).
Focus is very light weight and easy to wear using the AirSep-supplied shoulder
strap (Figure 4), or belt (Figure 3). You may clip the battery on to either the strap
or belt.
Focus can be worn on the waist by feeding the AirSep-supplied waist belt
(Figure 10) or the optional AirBelt, (Figure 11) through the loops on the back of
the Focus unit’s carrying bag. Focus can also be worn over the shoulder with the
use of the AirSep-supplied shoulder strap as shown (Figure 12).
Figure 10: Focus unit
worn on the waist
Figure 11: Focus unit
worn with AirBelt
Figure 12: Focus
unit worn with the
shoulder strap
Focus units Power
Inlet
Belt / Shoulder
Strap clip
Battery Gauge
