GPS 4100 General Instructions
Ag Leader Technology
March 2001 7
GPS SETUP
NMEA MESSAGE
GPS/PORT CONFIGURATION
BEACON DIFFERENTIAL
SATELLITE DIFFERENTIAL
LIGHTBAR
GUIDANCE
EDIT EXIT
Figure 3. GPS SETUP Screen
Step Action
3 At the GPS SETUP screen (Figure 3) scroll down to Satellite
Differential Mode with down arrow key and press EDIT. You
should now see the screen shown in Figure 4.
SATELLITE DIFFERENTIAL SETUP
Differential Source
WAAS
Differential Provider
Satellite Frequency 0000.0000
Satellite Baud Rate 0000
Provider User Code 0
OMNISTAR Code 000000000000000000000000
Subscription Expiration
00/00/0000
EDIT EXIT
Figure 4. Satellite Differential Setup Screen
Step Action
4 At the SATELLITE DIFFERENTIAL SETUP screen (Figure
4) Differential Source will be highlighted, press EDIT key and
use UP or DOWN ARROW key until WAAS is displayed and
press ACCEPT key.
5 Now press EXIT key to return to GPS SETUP screen, press
EXIT key again to return to the main operating screen.
