GPS 4100 Contents
Ag Leader Technology
March 2001 1
Important Notices
Before beginning installation of your GPS 4100, please take the time to
thoroughly read these instructions. Signal words (CAUTION,
IMPORTANT, and NOTE) are provided to draw attention to
information that is important for the safe/correct installation and
operation of this product.
•
CAUTION--will alert you to situations that will impact the
physical safety of you or others.
•
IMPORTANT—will alert you to the potential for damage to the
product or loss of data.
•
NOTE--will provide you with additional information to simplify a
procedure or clarify a process.
After completing installation of the GPS 4100 we recommend that you
place these instructions in the Options Section of your PF3000 or
PF3000 Pro Operator’s Manual to prevent their loss.
To receive upgrade/update information of this product you must send
in or fax the Registration Form. Refer to the Registration Form for
address and fax number.
Item Page
Updating Operating Program 2
Parts, Tools for Antenna Installation 3
Installing the Antenna 3
Routing the Cable to the Cab 4
General Information 6
WAAS Selection 6
Satellite Selection 8
Diagnostic Screen 14
NMEA Message 16
GPS/Port Configuration 16
Troubleshooting 17
Parts List 18
Updating GPS Firmware 19
Installing FlashLoader 19
Installing AgRemote 20
Commercial Satellite Frequencies and Contacts 21
