General Instructions GPS 4100
Ag Leader Technology
March 2001 14
Diagnostic Screen The diagnostic screen (Figure 13) provides troubleshooting and
reference information for the GPS. Provided are definitions of
screen terms.
Press the DIAG key to view Figure 13. Then press the Add-On
GPS key to view Figure 14.
GPS DIAGNOSTICS
UTC TIME 00:00:00
Latitude 0000.0000 S
Longitude 0000.0000 E
Elevation 0 ft
GPS speed 0.0 MPH
Number of satellites 0
Differential Status OFF
Beacon/Sat. Frequency 0.000
Differential SNR 0.0
HDOP/PDOP 0.00/0.00
Rcvr Voltage 13.73
ADD-ON
GPS
FORMAT
CARD
COPY TO
CARD
EXIT
Figure 13. GPS Diagnostics Screen
ADD-ON GPS DIAGNOSTICS DG
Product Id AL 9114
Trimble Firmware Version 1.71
Firmware Date 6/8/2000
Receiver Serial Number 0224004738
PV Filter Status ON
Everest Multipath OFF
Fast Update Rate OFF
Guidance Status OFF
EXIT
Figure 14. Add-On GPS Diagnostic Screen
