NMEA Messages The GPS unit uses Trimble TSIP to provide position information to the
PF3000. This means that NMEA messages (Figure 15) do not need to be
set and will not be displayed on the NMEA diagnostic screen.
NMEA MESSAGES
GGA ON
GLL OFF
VTG ON
GSV OFF
GSA OFF
ZDA OFF
ALM OFF
RMC OFF
MSS ON
EDIT EXIT
Figure 15. NMEA Messages Screen
GPS/Port
Configuration
The GPS/Port Configuration screen (Figure 14) requires no
adjustment at this time. This screen will be used for future options
for the AUX Port of the GPS.
GPS/PORT CONFIGURATION
Position Rate
1 Hz
NEMA Output rate ASAP
AUX port parity NONE
P/v FILTER ON
Port AUX
Output baud rate 19200
Output type NMEA
Input baud rate 19200
Input type None
EDIT EXIT
Figure 16. GPS/ Port Configuration Setup Screen
