Hydraulic Downforce
Quick Reference Guide
AL: 2006350 ENG Rev B
In
Manual
Control click the
increase arrow several
times. Does pressure
increase?
Troubleshooting Step 1B: Hydraulic Down Force
Go to Step 2:
Cables and Power
Yes
Yes
No
Move to softer ground or
pull forward. The opening
discs are not digging into the
ground.
Can
the gauge
wheels on the monitored
rows be turned by hand?
Return system to desired
control mode. Manual/
Automatic
Yes
Continued from Step 1A:
Hydraulic Down Force
Engage down force
hydraulics.
Decrease
pressure
in manual control.
Does the pressure
displayed go
down.
Go to Step 4:
Hydraulics
Troubleshooting Complete.
System should be in field-ready
state.
Put planter in down position
with load on gauge wheels.
Place in manual control at
maximum pressure.
Enter
down
force module
diagnostics. Do all row
sensors register a load
reading?
No
Go to Step 4:
Hydraulics
No
With planter still in down
position with load on gauge
wheels and in manual control
at maximum pressure
No
Yes
