Hydraulic Downforce
Quick Reference Guide
AL: 2006350 ENG Rev B
Power
Off
Solid
Red
Flashing
Red
Solid
Amber
Flashing
Amber
Solid
Green
Flashing
Green
Boot
No Power
N/A
No App
Running
N/A
N/A
N/A
Upgrade
No Power
N/A
N/A
N/A
Running
N/A
N/A
Main
Application
No Power
High Current
Power Low
N/A
N/A
N/A
Power OK
N/A
Light 1 (ISO CAN)
Boot
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Upgrade
Idle
Bus Off
N/A
Bus Error
Passive
Bus Error
Active
N/A
TX/RX
Main
Application
Idle
Bus Off
N/A
Bus Error
Passive
Bus Error
Active
N/A
TX/RX
Light 2 (Proprietary CAN)
Boot
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Upgrade
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Main
Application
Idle
Bus Off
N/A
Bus Error
Passive
Bus Error
Active
N/A
TX/RX
Local CAN
Off
Solid
Red
Flashing
Red
Solid
Amber
Flashing
Amber
Solid
Green
Flashing
Green
Boot
N/A
N/A
Upgrade
State
N/A
N/A
N/A
N/A
Main
Application
Idle
Bus Off
N/A
Bus Error
Passive
Bus Error
Active
N/A
CAN OK
Troubleshooting Step 5:
Indicator Lights
Power
Light 1
(ISO CAN)
Light 2
(Proprietary CAN)
Down Force
Row Unit Module
