11
Hydraulic Downforce
Quick Reference Guide
AL: 2006350 ENG Rev B
NOTE: A minimum of 1 implement switch (2 is recommended) must be installed
on planter for the down force system to work properly. If an implement switch is
already installed and connected to an existing SeedCommand module, no action is
required. If no implement switch is installed, action must be taken to install at least 1
implement switch and implement switch module on local down force CAN Bus.
When using the hydraulic down force module with existing Seed Command modules,
the implement switch must be connected to the module highest in the hierarchy
below:
Hydraulic Seed Rate Control Module
Clutch Control Module
Seed Tube Monitor Module
Implement switches connected to any non Seed Command related module will not
indicate planter up/down status for Hydraulic Down Force control. (App Rate Module
and Liquid Control Module included)
If none of the above 3 seed command modules are used then the Hydraulic Down
Force module must have a CAN implement switch installed.
Part numbers required for CAN implement switch installation:
Part Number Description
4002911 Module – CAN implement switch
4002658 Cable – CAN implement switch
4001507 Implement Switch
Implement Switch Kits (contain Implement Switch 4001507)
4100830 Kinze
4100831 John Deere
4100832 White
4100833 Case
Troubleshooting Step 3:
Implement Switch Connections
