Hydraulic Downforce

Quick Reference Guide

AL: 2006350 ENG Rev B

Hydraulic Down Force

Alarm Explanation and Resolution

Down Force Inadequate

Problem: System is at maximum hydraulic pressure, but does not achieve an acceptable gauge

wheel load. Often times this alarm occurs when down force actuators are lifting the planter tool

bar.

Resolution: Add weight to planter. If planter tool bar is not lifting, increase maximum down force set-

ting in configuration setup.

Hydraulic Pressure too low

Problem: Hydraulic pressure is at 0 and the system is demanding more pressure.

Resolution: Check hydraulic hoses for proper connections. Ensure SCV remote is set for continuous

flow. Zero each channel’s pressure sensor only when mechanical gauge reads 0 psi.

Low Gauge Wheel Load

Problem: Down force system is not achieving an acceptable gauge wheel load.

Resolution: Increase aggressiveness for problematic channel under settings button from run screen.

This alarm may be followed by Down Force Inadequate, in which case consult that alarm resolu-

tion section.

Pressure Sensor Failure

Problem: Pressure sensor is outside voltage range.

Resolution: swap cables with other channel (if applicable), re-zero pressure sensors. If problem

persists on same channel, replace pressure sensor. If problem is now on other channel, inspect/

replace cable.

Row Module Communication Lost

Problem: Row module communication lost.

Resolution: Inspect cabling of row module. Replace row module.

Row Module Failure

Problem: Row module is not sensing inputs. Row module is power cycling at intervals of less than 2

seconds

Resolution: Swap module with different row. If problem follows, replace module. If problem exists on

same row, inspect or replace load sensor.

# Row Modules does match the display configuration

Problem: Configuration was set to a number of sensors that was not detected by the system.

Resolution: Create a configuration that matches the number of sensors used. Check that all row

modules are communicating. Flashing green LED on the row module indicates proper communi-

cation.
