Description Field
• CCC is the LU number
•
XX:YY:ZZ is the LDKC number:CU number:LDEV number
The MU number of the BC pair formed with the P-VOL. MU
S-VOL information in AAA-BB-CCC(XX:YY:ZZ) format. S-VOL
•
AAA is the port ID (cluster and channel number)
•
BB is the group number of host group
• CCC is the LU number
•
XX:YY:ZZ is the LDKC number:CU number:LDEV number
Speed that data is copied according to the pair status. Copy Pace
P-VOL’s cache logical partition CLPR (P)
S-VOL’s cache logical partition CLPR (S)
If you click Apply and then the operations in the Preview list fail, an error code indicates
the cause of the error. Error Code
Data in the status bar below the Preview List indicate the number of changes, the type of change
(the operation), and any command options.
Pair Operation command menu
When you right-click a volume or pair, a menu displays. The following table describes the commands
that display.
Description Command
Opens the Detail dialog box, which displays detailed information for the selected volume
or pair. Detail
Opens the Paircreate dialog box, in which you create new pairs. Paircreate
Opens the Pairsplit dialog box, in which you split pairs. Pairsplit
Opens the Pairresync dialog box, in which you resynchronize pairs. Pairresync
Opens the Pairsplit-E dialog box, in which you suspend pairs. Pairsplit-E
Opens the Pairsplit-S dialog box, in which you delete pairs. Pairsplit-S
Opens the Set/Reset Reserve Attribute dialog box, in which you set/reset the S-VOL reserve
attribute. Change Reserve
Opens the S-VOL Path dialog box, which displays the S-VOL’s port or host group. S-VOL Path
Opens the Information dialog box, which displays the number of pairs or reserved volumes. Information
Display Filter dialog box
Use this dialog box to filter the volumes on the Pair Operations window. Click the Display Filter
button in the Pair Operation window to see the dialog box.
Pair Operation window 125
