HP StorageWorks All-in-One SB600c Storage Blade User Manual
Page 60
Table 27 Storage tab—HP All-in-One Storage System logical disk properties
Property
Value
System Name
Name the system uses to identify the logical disk.
Physical Disks
Globally unique identifier(s) of the hard drive(s) used by the logical disk
for storage.
Exclusive Storage
Indicates if the logical disk is configured with exclusive storage. See
on page 27 for more information.
RAID Level
The RAID level to which the logical disk is configured. See
on page 28 for more information.
RAID Stripe Size
The RAID stripe size to which the logical disk is configured. See
on page 27 for more information.
Read Cache
Speeds up reads when enabled. This setting is determined by the
storage array, not ASM.
Write Cache
Speeds up writes when enabled. This setting is determined by the
storage array, not ASM.
Number of Hot Spares
The number of hot spares with which the logical disk is configured. See
on page 27 for more information.
Unmanaged Data
Space on the logical disk used to store data that is not managed by ASM.
Free Space
Unused storage space on the logical disk that is not allocated.
Table 28 Storage tab—HP All-in-One Storage System volume properties
Property
Value
Storage Server Host Name
Name of your HP All-in-One Storage System.
Storage Server Volume - Name
Name of the volume on your HP All-in-One Storage System.
Storage Server Volume - Status
Status of the volume on your HP All-in-One Storage System.
Storage Server Volume - Exclusive
Storage
Indicates if volume is configured with exclusive storage. See
on page 27 for more information.
Storage Server Volume - RAID
Level
The RAID level to which the volume is configured. See
on page 28 for more information.
Storage Server Volume - RAID
Stripe Size
The RAID stripe size to which the volume is configured. See
on page 27 for more information.
Storage Server Volume - Read
Cache
Speeds up reads when enabled. This setting is determined by the
storage array, not ASM.
Storage Server Volume - Write
Cache
Speeds up writes when enabled. This setting is determined by the
storage array, not ASM.
Storage Server Volume - Number
of Hot Spares
The number of hot spares with which the shared folder’s storage is
configured. See
on page 27 for more information.
Storage Server Volume - Mount
Paths
Path on which the volume on your HP All-in-One Storage System is
mounted.
•
Warning Threshold tab—Allows you to change the percent full warning threshold value for the
user-defined application.
•
Data Protection tab—Allows you to schedule backups or run a backup of the user-defined
application data, or restore the user-defined application data from a backup. It also allows you to
schedule snapshots or take a snapshot of the user-defined application data, expose a snapshot,
or revert the user-defined application data to a past snapshot.
60
Monitoring storage
