5 Monitoring storage
ASM provides storage-management functions so you can quickly view used and allocated storage, and
percent full warning thresholds settings for application and shared folder storage on your HP All-in-One
Storage System. You have a choice of these views for the content pane:
, page 47—Monitoring the overall used and allocated storage values for specific
applications and shared folders (such as Exchange or SQL Server storage)
, page 58—Monitoring the used and allocated storage values for the logical disks
and volumes on your HP All-in-One Storage System that ASM created to host application storage
and shared folders.
, page 61—Monitoring the application servers with storage hosted on
your HP All-in-One Storage System.
, page 62—Monitoring the allocated storage values for specific
applications and the shared folders pool, the unallocated storage value, and the storage value for
data not managed by ASM.
Views are selected from the Actions pane.
You can also quickly view storage status on the content pane. Status icons for warnings and critical
conditions are displayed on top of icons in the content pane when storage status changes from OK to
Warning or Critical. See “
” on page 66 for more information on status icons.
NOTE:
Select an item in the content pane and then click Properties in the Actions pane to view any alerts for the
item. See “
” on page 66 for alert descriptions and troubleshooting information.
Application View
Application View displays the used and allocated storage space, and storage status of applications and
shared folders hosted on your HP All-in-One Storage System in the content pane.
•
In the Actions pane, select Application View.
•
To view all the application storage and shared folders hosted on your HP All-in-One Storage
System in the content pane, select All from the Filters drop-down menu, located at the top of the
content pane. See
on page 15 for more information.
Application storage properties are displayed in order of hierarchy in an expandable and collapsible view.
Click the Expand tree icon next to each application to view the used and allocated storage properties for
the hosted application components. Click the Collapse tree icon next to expanded applications to hide
the application component storage properties.
To view all the storage properties for an item listed in the content pane, see
Accessing application and shared folder properties
When Application View is selected in the Actions pane, you can view the storage status, alerts, and
properties for the following:
•
Applications
•
Application component
•
User-defined applications
All-in-One Storage Manager
47
