Page 55
• Select User-Defined in the content pane and then click Properties in the Actions pane.
or
• Right-click User-Defined in the content pane and select Properties.
For a user-defined application:
• Select any user-defined application in the content pane and then click Properties in the
Actions pane.
or
• Right-click any user-defined application in the content pane and select Properties.
Properties window
•
General tab—Displays the user-defined application name, name of the application server that
runs the user-defined application, and the application area status:
Table 20 Operating status—User-defined application properties
Status indicator
Value
OK
Application storage is online. No alerts.
Warning
See the Alerts list for more information. See
for alert descriptions.
Critical
See the Alerts list for more information. See
for alert descriptions.
•
Storage tab—Displays the user-defined application’s storage space, including allocated space,
used space, free space, and the following storage allocation details:
Table 21 Storage tab—User-defined application properties
Property
Value
Application Path
Path to the file directory on the application server where the
user-defined application data is saved by the user-defined application.
The file directory is located on the volume created on the iSCSI LUN
that was exported by ASM to the application server.
Protocol
Communication protocol used to transfer data between the server that
hosts the user-defined application and your HP All-in-One Storage
System.
Application Server Host Name
Name of server that hosts the user-defined application.
Application Server Volume -
Name
Name of the volume on the application server to which the
user-defined application saves its data. The volume resides on the
iSCSI LUN (logical disk) exported by ASM to the application server.
Application Server Volume -
Status
Status of the volume on the application server where the user-defined
application data is stored.
Application Server Volume -
Exclusive Storage
Indicates if user-defined application storage is configured with
exclusive storage. See
on page 27 for more information.
Application Server Volume -
RAID Level
The RAID level to which the user-defined application storage is
configured. See
on page 28 for more
information.
Application Server Volume -
RAID Stripe Size
The RAID stripe size to which the user-defined application storage is
configured. See
on page 27 for more information.
Application Server Volume -
Read Cache
Speeds up reads when enabled. This setting is determined by the
storage array, not ASM.
Application Server Volume -
Write Cache
Speeds up writes when enabled. This setting is determined by the
storage array, not ASM.
All-in-One Storage Manager
55
