Section 3: HP 5242-ACL Tape Drive
FRU 1 Dead Error On The controller board for the
embedded drive has failed
its self-test.
Call the HP GCSC.
FRU 2 Dead Error On The drive mechanism has
failed its self-test.
Call the HP GCSC.
FW Check Status Firmware upgrade data is
being checked for
compatibility.
FW Data
Err
Error Flashing The autoloader has failed
to upgrade the drive
firmware because the new
firmware is corrupt.
Obtain a good copy of
the firmware upgrade.
FW
Upgrade
Status Firmware upgrade data is
being read either through a
tape or the SCSI bus.
FW Read
Fail
Error Flashing A firmware upgrade failed
because of an error in
reading data from the tape.
Try again. If it still
fails, call the HP
GCSC.
FW Tape
Write
Protected
Error Flashing A firmware upgrade failed
because the tape is write-
protected.
Change the write-
protect switch on the
tape and try again.
FW Write
Fail
Error Flashing A firmware upgrade failed
because of an error in
writing a modified upgrade
count to the tape.
Try again. If it still
fails, call the HP
GCSC.
Illegal FW Error Flashing The autoloader has failed
to upgrade the drive
firmware because the new
firmware is incompatible.
Obtain a correct
version of the firmware
upgrade.
Illegal HW Error Flashing The autoloader has failed
to upgrade the drive
firmware because the new
firmware is for
incompatible hardware.
Obtain a correct
version of the firmware
upgrade.
Insert Mag Status The autoloader is waiting
for you to insert a
magazine.
Load Tape Info Displayed when you press
the Load Tape button.
Loading Status Either a cartridge is being
moved from the magazine
and placed into the drive
mechanism, or the drive is
loading a cartridge.
HP StorageWorks DAT 72 (Models 5242 and 5242-ACL) User's Guide 43 HP Part Number 528296-03 July 2005
