HP Integrity NonStop H-Series - Manual (Page 3)

v Table of Contents
Section 1 – General Information
Chapter One ......................................................................................………………………….1
Introduction.........................................................................………………………….1
Applications ........................................................................………………………….1
Software Prerequisites.........................................................………………………….1
SCSI Cables ........................................................................………………………….1
Component Part Numbers...................................................………………………….2
Cartridges............................................................................………………………….2
Write-Protecting a Cartridge ...............................................………………………….3
Labeled and Unlabeled Tapes .............................................………………………….3
Features...............................................................................………………………….3
Chapter Two......................................................................................………………………….5
SCSI Compatibility .............................................................………………………….5
DAT72 Format and Compatibility ......................................………………………….5
Chapter Three....................................................................................………………………….6
Installing the 5242 and 5242-ACL on Nonstop Servers……………………….…….6
Installation Overview..........................................................………………………….6
Installation Planning ......................................................………………………….7
Physical Specifications ..................................................………………………….7
Environment Specifications ...........................................………………………….7
AC Power Requirements................................................………………………….8
Unpacking ......................................................................………………………….9
Installing the Tape Drive................................................…………………………10
Connecting the SCSI Cable............................................…………………………11
Bringing the Tape Drive Online.....................................…………………………12
5242 Power-Up Sequence ..............................................…………………………13
5242-ACL Power-Up Sequence.....................................…………………………14
Checking and Setting SCSI the ID.................................…………………………15
Starting and Testing .......................................................…………………………17
Troubleshooting .............................................................…………………………18
Configuring the 5242 and 5242-ACL for Nonstop Servers.…………………………19
Chapter Four......................................................................................…………………………24
Preventive Maintenance......................................................…………………………24
5242 Tape Path Cleaning ....................................................…………………………24
5242-ACL Tape Path Cleaning...........................................…………………………25
Cleaning the Exterior ..........................................................…………………………26
Operating Environment.......................................................…………………………26
Chapter Five ......................................................................................…………………………27
Technical Support ...............................................................…………………………27
Chapter Six........................................................................................…………………………28
Cabling Limitations.............................................................…………………………28
Differential Devices ............................................................…………………………28
Cooling Fan and System .....................................................…………………………28
Specifications......................................................................…………………………28
Section 2 – 5242 Tape Drive
Chapter One ......................................................................................…………………………30
Introduction.........................................................................…………………………30
Features...............................................................................…………………………30
Chapter Two......................................................................................…………………………31
Loading and Unloading a Cartridge....................................…………………………31
Chapter Three....................................................................................…………………………32
Controls and Indicators .......................................................…………………………32
Understanding the LEDs.....................................................…………………………32
Chapter Four......................................................................................…………………………34
HP StorageWorks DAT 72 (Models 5242 and 5242ACL) User's Guide HP Part Number 528296-003 July 2005
Upgrading the Firmware From Tape...................................…………………………34
