Section 1: General Information
3.2.2.1 The 5242 User's Kit contains:
• One 68-pin high voltage differential terminator
• One 170 meter DAT72 data cartridge
• One cleaning cartridge
• One power cable
• One CD user manual
3.2.2.2 The 5242-ACL User's Kit contains:
• One 68-pin high voltage differential terminator
• One 170 meter DAT72 data cartridge
• One cleaning cartridge
• One 6-tape magazine
• One user manual on CD
3.2.2.3 To unpack the 5242 or 5242-ACL tape drive:
1. Use a utility knife to cut the tape holding the carton's top flaps closed.
2. Open the flaps and remove the User's Kit box.
3. Lift the enclosure and foam supports out of the container. Set on a flat level surface.
4. Carefully remove the foam supports from either end of the tape drive enclosure.
5. Inspect the tape drive for shipping damage.
Note:
Record any damage on the shipping bill. Report any damaged equipment to HP.
Failure to report damaged equipment immediately can result in a loss of claim.
6. Check you have:
• 5242 or 5242-ACL tape drive
• User's Kit containing user manual, terminator, and power cord. If you are using a
5242-ACL, you will also find a 6-tape magazine.
7. Move the 5242 or 5242-ACL tape drive into place. Note the service clearance
information. See Section 1, Chapter 3, Page 6.
8. Install the tape drive and connect it to the NonStop server. See the next section.
3.2.3
Installing the 5242 and 5242-ACL Tape Drive
This subsection describes the steps necessary to install the 5242 or 5242-ACL tape drives.
3.2.3.1 Connecting and Routing the AC Power Cord
An AC power cord connects the power supply in the 5242 and 5242-ACL tape drive to the
external power source. To connect an AC power cord to the 5242 and 5242-ACL tape
drives (assumes a non-computer-room installation):
1. Check that the AC power switch on the tape drive is set to the OFF (0) position. This
prevents power from being accidentally supplied to the tape drive.
2. Plug the AC power cord connector into the AC power receptacle at the rear of the tape
drive. See Figures 5 and 6.
3. Plug the other end of the AC power cord into the external power source. For
information about power requirements, see AC Power Requirements on page 8.
4. Move the 5242 or 5242-ACL tape drive into place. Note the service clearance
information under Service Clearance and Dimensions on page 6.
5. Install the 5242 or 5242-ACL tape drive and connect it to the NonStop server.
HP StorageWorks DAT 72 (Models 5242 and 5242-ACL) User's Guide 9 HP Part Number 528296-03 July 2005
