Section 1: General Information
3.2.1.4 AC Power Requirements
Each 5242 and 5242-ACL tape drive includes an auto ranging-power supply that accepts
input current in a voltage range of 115 volts AC to 230 volts AC at 50 hertz to 60 hertz. No
switch is required to change between ranges or between 50 hertz and 60 hertz.
Note: The power supply cannot be replaced as a subassembly. If the power supply fails,
you must replace the entire tape drive.
Power Volts 5242
Amperes
5242-ACL
Amperes
USA 60 Hz 110/120 0.6 1.0
Europe 50 Hz 220 0.3 0.5
Orient 50 Hz 200 0.3 0.5
Table 7 AC power requirements for the tape drive
Each tape drive includes a 1.8-meter (6-foot) AC power cord. One end of the power cord
plugs in to the socket near the AC power switch at the rear of the tape drive. The other end
of the power cord is routed to the AC power source. (See Connecting and Routing the AC
Power Cords, page 10).
3.2.2 Unpacking the 5242 and 5242-ACL Tape Drives
The 5242 and 5242-ACL tape drives are shipped in individual cartons. Each carton contains the tape
enclosure and a User's Kit. (See Figure 4.) A copper SCSI interface cable, if ordered, is shipped in a
separate box.
User's Kit
Tape
Subsystem
Enclosure
Shipping
Container
Foam
Supports
Figure 4 Unpacking a 5242 or 5242-ACL tape drive
HP StorageWorks DAT 72 (Models 5242 and 5242-ACL) User's Guide 8 HP Part Number 528296-03 July 2005
