• Reserved Capacity - displays the capacity of open volumes (LDEVs) in the storage system that
are reserved by Auto LUN. The percentage (%) to total capacity of open system volumes is
displayed in parentheses, as well as in the pie chart indicated by the pink area ( ). For
further information on Auto LUN, see the HP StorageWorks XP24000/XP20000 Auto LUN
Software User’s Guide.
• Pie chart and capacity by volume type when Mainframe Volume is selected:
The following capacities are displayed in MB when the Total Volume Capacity is 10 GB or less.
The following capacities are displayed in GB when the Total Volume Capacity is more than 10 GB.
• Allocated LDEV Capacity - displays the capacity of zSeries, S/390, and multiplatform volumes
(LDEVs) in the storage system that have assigned paths and are available to the user. The
percentage (%) to total capacity of zSeries, S/390, and multiplatform volumes is displayed in
parentheses, as well as in the pie chart indicated by the blue area ( ).
Note: It does not include reserved volumes of Auto LUN.
• Reserved Capacity - displays the capacity of zSeries, S/390, and multiplatform volumes
(LDEVs) in the storage system that are reserved by Auto LUN. The percentage (%) to total
capacity of zSeries, S/390, and multiplatform volumes is displayed in parentheses, as well as
in the pie chart indicated by the pink area ( ). For further information on Auto LUN, see the
HP StorageWorks XP24000/XP20000 Auto LUN Software User’s Guide.
• Total Volume Capacity displays the sum of allocated, unallocated (open system volume only), and
reserved volume capacities.
Number of LDEVs
The Number of LDEVs are on the lower right of the Remote Web Console main window.
• Allocated OPEN LDEVs - displays the number of open system volumes (LDEVs) that have assigned
paths. Note: Each of LDEVs that consist a LUSE volume is counted as one volume.
• Unallocated OPEN LDEVs - displays the number of open system volumes (LDEVs) that do not have
assigned paths. Note: It does not include reserved volumes of Auto LUN.
• Reserved OPEN LDEVs - displays the number of open system volumes (LDEVs) that are reserved by
Auto LUN.
• Allocated Mainframe LDEVs - displays the number of zSeries, S/390, and multiplatform volumes
(LDEVs) that have assigned paths. Note: It does not include reserved volumes of Auto LUN.
• Reserved Mainframe LDEVs - displays the number of zSeries, S/390, and multiplatform volumes
(LDEVs) that are reserved by Auto LUN.
• V-VOL - displays the number of V-VOLs that are virtual volumes (LDEVs) that do not consume
the actual disk capacity. V-VOLs are currently used for XP Snapshot and XP Thin Provisioning.
For details, see the HP StorageWorks XP24000/XP20000 Snapshot User’s Guide or the HP
StorageWorks XP Thin Provisioning Software User's Guide.
• Total (All LDEVs) - displays the sum of allocated OPEN LDEVs, unallocated OPEN LDEVs, reserved
OPEN LDEVs, allocated Mainframe LDEVs, reserved Mainframe LDEVs, and V-VOLs.
Port Status Window
The Port Status window displays the port information using the image of the ports mounted on the
storage system.
To open the Port Status window, log in to the Remote Web Console, and then click Go, System
Information and Port Status on the menu bar of the Remote Web Console main window.
Note: Storage partition administrators cannot display the Port Status window.
