Command line 84
Name RFC Description
mechanism in the PLS Carrier Sense
Function as described in IEEE Std.
802.3, 1998 Edition, section
7.2.4.6. This counter does not
increment on interfaces operating at
speeds greater than 10 Mb/s, or on
interfaces operating in full-duplex
mode. Discontinuities in the value of
this counter can occur at
re-initialization of the management
system, and at other times as
indicated by the value of
ifCounterDiscontinuityTime.
rfc2665_Dot3StatsSingleColli
sionFrames
2665 A count of successfully transmitted
frames on a particular interface for
which transmission is inhibited by
exactly one collision. A frame that is
counted by an instance of this object
is also counted by the corresponding
instance of either the ifOutUcastPkts,
ifOutMulticastPkts, or
ifOutBroadcastPkts, and is not
counted by the corresponding
instance of the
dot3StatsMultipleCollisionFrames
object. This counter does not
increment when the interface is
operating in full-duplex mode.
Discontinuities in the value of this
counter can occur at re-initialization
of the management system, and at
other times as indicated by the value
of ifCounterDiscontinuityTime.
rfc2665_Dot3StatsSymbolErr
ors
2665 For an interface operating at 100
Mb/s, the number of times there was
an invalid data symbol when a valid
carrier was present.
For an interface operating in
half-duplex mode at 1000 Mb/s, the
number of times the receiving media
is non-idle (a carrier event) for a
period of time equal to or greater
than slotTime, and during which
there was at least one occurrence of
an event that causes the PHY to
indicate 'Data reception error' or
'carrier extend error' on the GMII.
For an interface operating in
full-duplex mode at 1000 Mb/s, the
number of times the receiving media
is non-idle a carrier event) for a
period of time equal to or greater
than minFrameSize, and during
which there was at least one
