LUN Configuration and Security Manager XP user guide for the XP12000/XP10000/SVS200 173
• CU:LDEV: CU:LDEV number of the CVS volume to be created.
NOTE:
If an LDEV number ends with # (for example, 00:01#), the LDEV is an external LU. For
more information about external LUs, see the HP StorageWorks External Storage XP user guide.
NOTE:
If an LDEV number ends with V (for example, 00:00V), the LDEV is a virtual volume
(V-VOL). For more information about virtual volumes, see the HP StorageWorks Snapshot XP user
guide.
•
Back: Returns to the Make Volume pane (2) or Make Volume pane (3).
•
OK: Registers the Make Volume settings, and returns to the Customized Volume pane.
•
Cancel: Cancels the Make Volume settings, and returns to the Customized Volume pane.
Volume Initialize pane (1)
Use this pane to initialize CVS volumes other than OPEN-V.
Figure 104
Volume Initialize pane (1)
This pane has the following features:
•
Normal volume-setting information table: On the upper right of the pane, displays detailed information
about the CVS volumes to be initialized.
• Parity Group: Number of the VDEV to be initialized. The VDEV number indicates the parity group
where the VDEV belongs. For example, if VDEV number 1-1-(1) appears, the VDEV belongs to
parity group number 1-1.
NOTE:
If a VDEV number starts with E (for example, E1-1-(1)), the VDEV belongs to a parity group
that consists of one or more external LUs.
NOTE:
If a VDEV number starts with V (for example, V1-1-(1)), the VDEV belongs to a parity
group that consists of one or more virtual volumes (V-VOLs).
• No.: Setting number of the CVS volume to be initialized.
• Emulation: Emulation type of the CVS volume to be initialized.
