NOTE:
The vCenter Store Credentials file should be set to allow access permission for the
administrative group and system account.
5.
Click Open.
6.
Select vCenter name to map.
7.
Click Select.
The VASA Tab
A VASA Provider is a software component that acts as a server in the vSphere environment. A
vCenter Server connects to the VASA Provider to obtain information about available storage
topology, capabilities, and state. The vCenter Server can then provide the appropriate information
to vSphere clients.
VASA Configuration
The VASA Configuration option is used to examine and configure VASA capabilities for your
installation. (
).
Figure 27 VASA Configuration
The selections available from VASA Configuration screen are described in
Table 4 VASA Configuration Options
Description
Field
Shows the port to which the VASA web service is binding.
VASA service TCP port
Shows whether secure service is selected.
Secure service
Shows the URL address required to connect to VASA web service.
Web service URL
Shows the folder where log files are stored.
Log folder
Specifies the level of verbosity for the log file.
Debug level
The default value is Medium.
To modify the VASA configuration options:
