Description Item
Cancels the settings for the LDEV, and returns to the
Customized Volume window. Cancel
Removes an LDKC:CU:LDEV number that is already
assigned. To remove an LDKC:CU:LDEV number, select a
VLL volume number corresponding to the LDKC:CU:LDEV
number that you want to remove, right-click, and select
Clear. Clear
Table 17 Emulation Groups
D-type (Overseas PCM) emulation type Emulation group
3390-3, 3390-3A, 3390-3B, 3390-3C, 3390-9, 3390-9A,
3390-9B, 3390-9C, 3390-L, 3390-LA, 3390-LB, 3390-LC,
3390-M, 3390-MA, 3390-MB, 3390-MC Group 1
3390-3R Group 2
OPEN-3, OPEN-8, OPEN-9, OPEN-E Group 4
OPEN-V Group 6
Set SSID (Install CV) Dialog Box
The Set SSID (Install CV) dialog box opens during the creation of VLL volumes if the boundary area
of the selected LDEV number does not have an SSID. Use this dialog box to set an SSID.
36 Using the Virtual LVI/LUN and Volume Shredder GUI
