Figure 11 Install CV Confirmation Dialog Box
Description Item
VDEV number for the VLL volume to be created.
• A VDEV number that starts with E (for example, E1-1-(1))
indicates that the VDEV belongs to a parity group that
consists of one or more external LUs.
•
A VDEV number that starts with V (for example, V1-1-(1))
indicates that the VDEV belongs to a parity group that
consists of one or more XP Snapshot virtual volumes
(V-VOLs).
•
A VDEV number that starts with X (for example, X1-1-(1))
indicates that the VDEV belongs to a parity group that
consists of one or more XP Thin Provisioning virtual
volumes (V-VOLs).
VDEV
Emulation type of the VLL volume to be created. Emulation
Capacity of the VLL volume displayed in the unit selected
from the Capacity Unit list in the Install CV dialog box (1). Capacity
The LDKC number, the CU number, and the LDEV number
of the VLL volume to be created. LDKC:CU:LDEV
Shows System Disk if the VLL volume is configured as a
system disk. Option
Returns to the previous dialog box. Back
Registers the Install CV settings, and returns to the
Customized Volume window. OK
Cancels the Install CV settings, and returns to the
Customized Volume window. Cancel
Install CV Confirmation Dialog Box 41
