Monitoring System Activity and Performance LTPH-UM-1049-02, Issue 2
44 January 9, 2002 H2TU-C-319 List 4E
U
SING THE
P
ERFORMANCE
S
CREENS TO
V
IEW
A
LARM
D
ATA
To access the alarm history screens:
1 Press to select the Performance menu.
2 Press the to select an interface (H2TU-C DS1, H2TU-R DS1, H2TU-C HDSL2, or
H2TU-R HDSL2), then press .
3 Press the until Alarm History is selected, then press .
• Press or to page through the alarm history screens.
• Press to clear the selected alarm history screen.
Alarm History at the DS1 Interface
The Alarm History screen reports DS1 statistics for the H2TU-C, shown in Figure 25 below, and the H2TU-R,
shown in Figure 26 on page 45 , on a continuous basis. The types of alarms reported are described in Table 17 on
page 45 . Current alarms are shown in reverse video.
Figure 25. H2TU-C DS1 Alarm History Screen
P
SPACEBAR
ENTER
SPACEBAR ENTER
N P
L
Monitor Performance Event Log Config Inventory Report Rlogon Help
H2TU-C DS-1 Alarm History
-----------------------------------------------------------------------------
Alarm First Last Status Count
SPTE OK 0
SPTF OK 0
LLOS OK 0
LAIS OK 0
DBER DISABLED 0
Press: C(l)ear Alarm History
------------------------------------------------------------------------------
Use to cycle through Interface : H2TU-C DS-1
choices and to view Statistics : Alarm History
ID: xxxx--xxxx--xxxx--xxxx 08/01/2001 07:05:33 H2TU-C System: Alarm
