Figure 7. Config Menu - Standard Options (defaults shown)
Figure 8. Config Menu - ADC Options (defaults shown)
Monitor Performance Event Log Config Inventory Report Rlogon Help
+-----------------------+
|
Standard Options -> |
+-----------------------------------------------------+
| Loopback Timeout (LBTO)
: 120 min |
| Loop Attenuation Threshold (LATT) [0-40] : 32 dB |
| Margin Threshold (MARG) [0-15]: 5 dB |
| DS1 Frame Formatting (FRMG) : AUTO |
| DS1 Line coding (DS1) : B8ZS |
| H2TU-C Equalization (EQL) : 0 ft |
| H2TU-R Line Buildout (RLBO) : -7.5 dB |
| Alarm Pattern (ALMP) : AIS |
| H2TU-R TLOS Loopback (TLOS) : DIS |
| Power Back Off Network (PBON) : DEF |
| Power Back Off Customer (PBOC) : DEF |
+-----------------------------------------------------+
Use to cycle through option settings and to activate
ID: xxxx--xxxx--xxxx--xxxx 08/01/2001 06:43:31 H2TU-C System: OK
Monitor Performance Event Log Config Inventory Report Rlogon Help
+-----------------------+
| Standard Options
-> |
| ADC Options -> |
+-------------------------------------------------+
| Line Power Feed (PWRF)
: ON |
| Remote Provisioning (RTPV) : ENA |
| Bipolar Violation Transparency (BPVT) : DIS |
| DS1 BER (DBER) : DIS |
| HDSL2 BER Threshold (HBER) : 1E-6 |
| Special Loopback Mode (SPLB) : GNLB |
| Smartjack Loopback (LPBK) : ENA |
| Minor Alarm (ALM) : DIS |
| Network AIS Pattern (NAIS) : CI |
| Performance Report Messaging (PRM) : S+N |
| SF-RAI to SF-RAI-CI toward NET (RACI) : ENA |
| ESF-RAI to SF-RAI Overwrite (ROVR) : ENA |
| H2TU-R DS1 Frame Conversion (CONV) : ACON |
| Fractional T1 Mode (FT1) : DIS |
| Active DS1 Port (ADS1) : MUX |
+-------------------------------------------------+
Use to cycle through option settings and to activate
ID: xxxx--xxxx--xxxx--xxxx 08/01/2001 06:43:31 H2TU-C System: OK
