Monitoring System Activity and Performance LTPH-UM-1049-02, Issue 2
42 January 9, 2002 H2TU-C-319 List 4E
Current Statistics Screens for the DS1 Interface
Examples of current statistics screens are shown below. Figure 22 and Figure 23 show statistics for the DS1
interface at the remote unit and line unit, respectively. These screens report 1-day, 1-hour, and 15-minute statistics.
Refer to
Table 15 on page 39 for descriptions of the kinds of errors reported on these screens.
Figure 22. H2TU-R DS1 Current Statistics
Figure 23. H2TU-C DS1 Current Statistics
Monitor Performance Event Log Config Inventory Report Rlogon Help
H2TU-R DS-1 Current Statistics
-----------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 00:00 12:00 12:30
CV-L 0 0 0
ES-L 0 0 0
SES-L 0 0 0
UAS-L 0 0 0
PDVS-L 0 0 0
ES-P 0 0 0
SES-P 0 0 0
UAS-P 0 0 0
PRM-NE No PRM Detected
PRM-FE No PRM Detected
B8ZSS 0 0 0
MSEC 3482 1801 1
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Use to cycle through Interface : H2TU-R DS-1
choices and to view Statistics : Current
ID: xxxx--xxxx--xxxx--xxxx 08/01/2001 07:05:33 H2TU-C System: OK
Monitor Performance Event Log Config Inventory Report Rlogon Help
H2TU-C DS-1 Current Statistics
-----------------------------------------------------------------------------
1 Day 1 Hour 15 Min
Start 00:00 12:00 12:30
CV-L 0 0 0
ES-L 0 0 0
SES-L 0 0 0
UAS-L 0 0 0
PDVS-L 0 0 0
ES-P 0 0 0
SES-P 0 0 0
UAS-P 0 0 0
B8ZSS 0 0 0
MSEC 3482 1801 1
Press: C(l)ear Current Statistics
------------------------------------------------------------------------------
Use to cycle through Interface : H2TU-C DS-1
choices and to view Statistics : Current
ID: xxxx--xxxx--xxxx--xxxx 08/01/2001 07:05:33 H2TU-C System: OK
