Performance History at the HDSL2 Interface
The HDSL2 interface has 31-day, 48-hour, 25-hour, and current statistic screens for the H2TU-C. Figure 19 and
Figure 20 below are examples of 31-day and 48-hour performance history screens. Figure 21 on page 41 is an
example of a 25-hour performance history screen. Refer to Table 16 on page 41 for descriptions of the kinds of
errors reported on all HDSL2 performance screens. Asterisks indicate performance monitoring from the previous
day.
Figure 19. H2TU-C HDSL2 31-Day Performance History
Figure 20. H2TU-C HDSL2 48-Hour Performance History
Monitor Performance Event Log Config Inventory Report Rlogon Help
H2TU-C HDSL2 31 Day History (Page 1 of 3)
-----------------------------------------------------------------------------
Date CV ES SES UAS LOSWS
10/09 - - - - -
10/10 - - - - -
10/11 - - - - -
10/12 - - - - -
10/13 - - - - -
10/14 - - - - -
10/15 - - - - -
10/16 - - - - -
10/17 - - - - -
10/18 - - - - -
10/19 - - - - -
10/20 - - - - -
10/21 14 10 10 14 10
Press: (N)ext Page, (P)revious Page, C(l)ear History
-----------------------------------------------------------------------------
Use to cycle through Interface : H2TU-C HDSL2
choices and to view Statistics : 31 Day History
ID: xxxx--xxxx--xxxx--xxxx 08/01/2001 07:05:33 H2TU-C System: OK
Monitor Performance Event Log Config Inventory Report Rlogon Help
H2TU-C HDSL2 48 Hour History (Page 1 of 4)
------------------------------------------------------------------------------
Time CV ES SES UAS LOSWS
*00:00 - - - - -
*01:00 - - - - -
*02:00 - - - - -
*03:00 - - - - -
*04:00 - - - - -
*05:00 - - - - -
*06:00 - - - - -
*07:00 - - - - -
*08:00 - - - - -
*09:00 - - - - -
*10:00 - - - - -
*11:00 - - - - -
Press: (N)ext Page, (P)revious Page, C(l)ear History
-----------------------------------------------------------------------------
Use to cycle through Interface : H2TU-C HDSL2
choices and to view Statistics : 48 Hour History
ID: xxxx--xxxx--xxxx--xxxx 08/01/2001 07:05:33 H2TU-C System: OK
