ADC HiGain H2TU-C-319 List 4E User Manual
Page 29
LTPH-UM-1049-02, Issue 2
Provisioning
H2TU-C-319 List 4E
January 9, 2002
21
Active DS1 Port
See
.
ADS1
MUX
The MUX mode selects the DSX-1 (MUX) port as the active source for the DS1
Signal to transmit to the HSDL Line Port #1.
An AIS signal is sent to the auxiliary Port #2. Equalizer settings apply to the
MUX DSX-1 port. The AUX equalizer is set to 0.
AUX
The AUX mode selects the auxiliary DSX-1 Port #2 as the active source for
DS1 signal to transmit to the HDSL Line Port.
In this case, the MUX port is used as a monitor or splitting device for electrical
test access. Equalizer settings apply to the AUX DSX-1 port. The MUX
equalizer is set to 0.
CTHR
Activates the Cut-through mode. This mode electrically connects the MUX
port to the AUX port and the H2TU-C operates as a cut-through card.
This is used when one tributary from the Wideband 3190 MUX card is required
to appear at the DSX-1 interface to the local central office. Equalizer settings
apply to the MUX DSX-1 port. The AUX Equalizer is set to 0.
Table 6.
H2TU-C-319 List 4E ADC Config Menu Options (Continued)
ADC Config Menu
Options
Front-Panel
Display
Code
Selection
Description
