ix
SABERTOOTH Z77 specifications summary
(continued on the next page)
CPU LGA 1155 socket for Intel ® 3rd/2nd generation Core™ i7/i5/i3/
Pentium ® /Celeron ® Processors
Supports 22/32nm CPU
Supports Intel ® Turbo Boost Technology 2.0
* The Intel ® Turbo Boost Technology 2.0 support depends on the
CPU types
** Refer to www.asus.com for Intel CPU support list
Chipset Intel ® Z77 Express Chipset
Memory 4 x DIMM, Max. 32GB, DDR3 1866/1600/1333/1066 MHz,
non-ECC, un-buffered memory
Dual channel memory architecture
Supports Intel ® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics
of the individual CPUs. Please refer to Memory QVL (Qualified
Vendors) list for details.
** Refer to www.asus.com or this user manual for the Memory
QVL (Qualified Vendors Lists)
Expansion Slots 2 x PCI Express 3.0*/2.0 x16 slots (single at x16, dual at x8/x8)
1 x PCI Express 2.0 x16 slot** [black] (Max. at x4 mode,
compatible with PCIe x1 and x4 devices)
3 x PCI Express 2.0 x1 slots
* PCIe 3.0 speed is supported by Intel ® 3rd generation Core™
processors.
** The PCIe 2.0 x16 slot shares bandwidth with PCIe 2.0 x1_1
slot, PCIe 2.0 x1_2 slot, and PCIe 2.0 x1_3 slot. The PCIe 2.0
x16 slot default setting is in x1 mode.
Multi-GPU Support Integrated Graphics Processor - Intel HD Graphics support
Supports NVIDIA ® Quad-GPU SLI™ Technology
Supports AMD ® Quad-GPU CrossFireX™ Technology
Supports LucidLogix Virtu MVP Technology*
* LucidLogix Virtu MVP supports Windows 7 operating systems.
Storage Intel ® Z77 Express Chipset
- 2 x SATA 6Gb/s ports (brown) with RAID 0,1, 5, and 10 support
- 4 x SATA 3Gb/s ports (black) with RAID 0,1, 5, and 10 support
- Supports Intel ® Smart Response Technology, and Intel ® Rapid
Start Technology*
2 x ASMedia
® 1061 SATA controllers**
- 2 x SATA 6Gb/s ports (gray)
- 2 x eSATA 6Gb/s ports (red)
* Supports on Intel ® Core processor family with Windows 7
operating systems.
** These SATA ports are for data hard drivers only. ATAPI devices
are not supported.
LAN Intel ® 82579V Gigabit LAN controller
Audio Realtek ® ALC892 8-channel High Definition Audio CODEC
- Absolute Pitch 192khz/24bit True BD Lossless Sound
- BD Audio Layer Content Protection
- Supports Jack-Detection, Multi-Streaming, and Front Panel
Jack-Retasking
- Optical S/PDIF Out port at back I/O
