3-40 Chapter 3: BIOS setup
Chapter 3
Label
Allows you to input the label of setup profile.
Save to Profile
Allows you to save the current BIOS settings to the BIOS Flash, and create a profile. Key in
a profile number from one to eight, press , and select Yes. You can also do this by or
keying the <+> or <->, press and select Yes.
Load from Profile
Allows you to load the previous BIOS settings saved in the BIOS Flash. Key in a profile
number from one to eight, press , and select Yes. You can also do this by or keying
the <+> or <->, press and select Yes.
• DO NOT shut down or reset the system while updating the BIOS to prevent the
system boot failure!
• We recommend that you update the BIOS file only coming from the same memory/CPU
configuration and BIOS version.
3.8.3. ASUS SPD Information
This item allows you to view the DRAM SPD information.
Main Ai Tweaker Advanced Monitor Boot
DIMM Slot number
Back Tool\ ASUS SPD Information >
UEFI BIOS Utility - Advanced Mode
Tool
DIMM Slot # DIMM_A2
Manufacturer Samsung
Module Size 1024 MBytes
Maximum Bandwidth 1333 Mhz
Part Number M391B2873DZ1-CH9
Serial Number 060369f9
Product Week/Year 50/2011
SPD Ext.
JEDEC ID JEDEC
Frequency(Mhz) 1333 1600
Voltage (V) 1.500 1.650
CAS# Lantency (tCL) 9 9
RAS# to CAS# (tRCD) 9 9
RAS# Precharge(tRP) 9 9
tRAS 24 27
tRC 33 36
tWR 10 12
tRRD 4 5
tRFC 74 88
tWTR 5 6
tRTP 5 6
tFAW 20 24
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
DIMM Slot # [DIMM_A2]
Allows you to view the information of the DIMM slots.
Configuration options: [Slot 1] [Slot 2] [Slot 3] [Slot 4]
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
