ASUS SABERTOOTH Z77 3-21
Chapter 3
3.5.1 CPU Configuration
The items in this menu show the CPU-related information that the BIOS automatically
detects.
The items shown in this screen may be different due to the CPU you installed.
Scroll down to display the following items:
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
Adjust Non-Turbo Ratio
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
Back Advanced\ CPU Configuration >
UEFI BIOS Utility - Advanced Mode
CPU Configuration
Intel(R) Core(TM) i3-2130 CPU 0 @ 3.40GHz
EM64T Supported
Processor Speed 3400 MHz
Processor Stepping 206a7
Microcode Revision 25
L1 Data Cache 32 kB x 4
L1 Code Cache 32 kB x 4
L2 Cache 256 kB x 4
L3 Cache 3072 kB
Processor Cores 2
Intel HT Technology Supported
CPU Ratio Range 16-34
CPU Current Ratio 34
Intel Adaptive Thermal Monitor Enabled
Hyper-threading Enabled
Active Processor Cores All
Limit CPUID Maximum Disabled
Execute Disable Bit Enabled
Intel Virtualization Technology Disabled
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
Hardware Prefetcher Enabled
Adjacent Cache Line Prefetch Enabled
> CPU Power Management Configuration
Intel Adaptive Thermal Monitor [Enabled]
[Disabled] Disables the CPU thermal monitor function.
[Enabled] Enables the overheated CPU to throttle its clock speed to cool down.
Hyper-threading [Enabled]
The Intel ® Hyper-Threading Technology allows a hyper-threading processor to appear as two
logical processors to the operating system, allowing the operating system to schedule two
threads, or processes simultaneously.
[Enabled]
Two threads per activated core are enabled.
[Disabled] Only one thread per activated core is enabled.
