2 cpu installation, Cpu installation -27, Chapter 2 – Asus SABERTOOTH Z77 User Manual
Page 47
ASUS SABERTOOTH Z77
2-27
Chapter 2
2.3.2
CPU installation
Please note the order in opening/ closing the double latch. Follow the instructions printed
on the metal sealing hatch or the illustrations shown below in this manual. The plastic cap
will pop up automatically once the CPU is in place and the hatch properly sealed down.
1
2
3
A
B
