ASUS SABERTOOTH Z77 3-11
Chapter 3
Primary Timings
DRAM CAS# Latency [Auto]
Configuration options: [Auto] [3 DRAM Clock] – [15 DRAM Clock]
DRAM RAS# to CAS# Delay [Auto]
Configuration options: [Auto] [4 DRAM Clock] – [15 DRAM Clock]
DRAM RAS# PRE Time [Auto]
Configuration options: [Auto] [4 DRAM Clock] – [15 DRAM Clock]
DRAM RAS# ACT Time [Auto]
Configuration options: [Auto] [4 DRAM Clock] – [40 DRAM Clock]
DRAM COMMAND Mode [Auto]
Configuration options: [Auto] [1 DRAM Clock] [2 DRAM Clock] [3 DRAM Clock]
Secondary Timings
DRAM RAS# to RAS# Delay [Auto]
Configuration options: [Auto] [4 DRAM Clock] – [7 DRAM Clock]
DRAM REF Cycle Time [Auto]
Configuration options: [Auto] [48 DRAM Clock] – [511 DRAM Clock]
DRAM Refresh Interval [Auto]
Configuration options: [Auto] [48 DRAM Clock] – [511 DRAM Clock]
DRAM WRITE Recovery Time [Auto]
Configuration options: [Auto] [5 DRAM Clock] – [31 DRAM Clock]
DRAM READ to PRE Time [Auto]
Configuration options: [Auto] [4 DRAM Clock] – [15 DRAM Clock]
DRAM FOUR ACT WIN Time [Auto]
Configuration options: [Auto] [16 DRAM Clock] – [63 DRAM Clock]
Scroll down to display the following items:
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
DRAM CLK Period Auto
Transmitter Slew(CHA) Auto
Transmitter Slew(CHB) Auto
Receiver Slew(CHA) Auto
Receiver Slew(CHB) Auto
MCH Duty Sense (CHA) Auto
MCH Duty Sense (CHB) Auto
Channel A DIMM Control Enable Both . . .
Channel B DIMM Control Enable Both . . .
DRAM Read Additional Swizzle Auto
DRAM Write Additional Swizzle Auto
