2-38

Chapter 2: Hardware information

Chapter 2

2.3.9

Front I/O Connector

IDE_LED

POWER SW

RESET SW

IDE_LED-

IDE_LED+

PWR

Reset

Ground

Ground

1

2

To install ASUS Q-Connector

USB 2.0

AAFP

To install USB 2.0 Connector

To install front panel audio

connector

USB 3.0

To install USB 3.0 Connector

Remove the USB dust cover before

installing the USB 2.0 connector.
