ASUS SABERTOOTH Z77 3-17
Chapter 3
iGPU Current Capability [100%]
Allows you to set the iGPU Current Capability.
Configuration options: [100%] [110%] [120%] [130%] [140%]
DO NOT remove the thermal module while changing the DIGI+ VRM related parrameters .
The thermal conditions should be monitored.
Some of the following items above are adjusted by typing the desired values using the
numeric keypad and press the key. You can also use the <+> and <-> keys to
adjust the value. To restore the default setting, type [auto] using the keyboard and press the
key.
DRAM Current Capability [100%]
Allows you to set the DRAM Current Capability to a higher value for a wider total power
range, and extends the overclocking frequency range.
Configuration options: [100%] [110%] [120%] [130%]
DRAM Voltage Frequency [Auto]
Allows you to adjust the DRAM switching frequency.
Configuration options: [Auto] [Manual]
DRAM Power Phase Control [Auto]
Allows you to set the tuning profile
[Auto] Sets the default configuration.
[Optimized] Sets the ASUS optimized phase tuning profile.
[Extreme] Sets the full phase mode.
DRAM Power Thermal Control [110]
Allows you to set a higher temperature for a wider DRAM power thermal range, and
extends the overclocking tolerance for overclocking potential.
Press <+> or <-> to set a value.
DO NOT remove the thermal module. Thermal conditions must be monitored regularly.
CPU Voltage [Offset Mode]
[Manual Mode] Allows you to set a fixed CPU voltage.
[Offset Mode] Allows you to set the Offset voltage.
Offset Mode Sign [+]
This item appears only when you set the CPU Voltage item to [Offset Mode].
[+]
To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Offset Voltage [Auto]
This item appears only when you set the CPU Voltage item to [Offset Mode] and
allows you to set the Offset voltage. The values range from 0.005V to 0.635V with a
0.005V interval.
