ASUS SABERTOOTH Z77

2-3

Chapter 2

Layout contents

Connectors/Jumpers/Slots

Page

ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)

2-24

CPU, chassis, and assistant fan connectors

(4-pin CPU_FAN, CHA_FAN1–4, CPU_OPT, 3-pin ASST_FAN)

2-22

LGA1155 CPU socket

2-4

DDR3 DIMM slots

2-5

MemOK! switch

2-15

USB 3.0 connector (20-1 pin USB3_34)

2-20

Intel

Z77 Serial ATA 6Gb/s connectors

(7-pin SATA6G_1/2 [brown])

2-17

Intel

Z77 Serial ATA 3Gb/s connectors

(7-pin SATA3G_3–6 [black])

2-18

ASMedia

Serial ATA 6Gb/s connectors

(7-pin SATA6G_E1/E2 [gray])

2-19

10.

System panel connector (20-8 pin PANEL)

2-25

11.

USB 2.0 connectors (10-1 pin USB56, USB78, USB910)

2-21

12.

Standby power LED (SB_PWR)

2-16

13.

Clear RTC RAM (3-pin CLRTC)

2-14

14.

Front panel audio connector (10-1 pin AAFP)

2-23

15.

Digital audio connector (4-1 pin SPDIF_OUT)

2-21
