ASUS SABERTOOTH Z77 3-35
Chapter 3
Chassis 1/2/3/4 Lower Temperature [40]
Displays the lower limit of the chassis temperature.
Chassis 1/2/3/4 Fan Min. Duty Cycle(%) [60]
Use the <+> and <-> keys to adjust the minimum chassis fan duty cycle. The values range from
60% to 100%. When the chassis temperature is under 40ºC, the chassis fan will operate at the
minimum duty cycle.
ASST 1/2 Q-Fan Control [Enabled]
[Disabled] Disables the Assistant Q-Fan control feature.
[Enabled] Enables the Assistant Q-Fan control feature.
Assistant 1/2 Fan Speed Low Limit [600 RPM]
This item appears only when you enable the ASST 1/2 Q-Fan Control feature and allows
you to disable or set the chassis fan warning speed.
Configuration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
ASST 1/2 Fan Profile [Standard]
This item appears only when you enable the ASST 1/2 Q-Fan Control feature and
allows you to set the appropriate performance level of the assistant fan.
[Standard] Sets to [Standard] to make the assistant fan automatically adjust
depending on the assistant temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet assistant fan operation.
[Turbo] Sets to [Turbo] to achieve maximum assistant fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
[Fan-off] Sets to [Fan-off] to allow assistant fans to run at 0% duty cycle when the
motherboard’s temperature decreases to a cetain degree.
The following four items appear only when you set ASST 1/2 Fan Profile to [Manual].
ASST 1/2 Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the assistant/PCH temperature. The values
range from 40ºC to 90ºC.
ASST 1/2 Fan Max. Duty Cycle(%) [100]
Use the <+> and <-> keys to adjust the maximum assistant/PCH fan duty cycle. The values
range from 60% to 100%. The minimum value can not lower than the setting of Min duty cycle.
When the assistant/PCH temperature reaches 95 degree, fan will run up to full speed.
ASST 1/2 Lower Temperature [40]
Displays the lower limit of the assistant/PCH temperature.
ASST 1/2 Fan Min. Duty Cycle(%) [60]
Use the <+> and <-> keys to adjust the minimum assistant/PCH fan duty cycle. The values
range from 60% to 100%. When the assistant/PCH temperature is under 40ºC, the assistant/
PCH fan will operate at the minimum duty cycle.
